⚙️ Main Specifications
🔹 Model: HEX6000CS
🔹 Brand: Dorin
🔹 Series: HEX7
🔹 Type: Semi-Hermetic Reciprocating Compressor
🔹 Number of Cylinders: 8
🔹 Displacement @ 50 Hz: 199.86 m³/h
🔹 Displacement @ 60 Hz: 239.83 m³/h
🔹 Bore: 75 mm
🔹 Stroke: 65 mm
🔹 Oil Charge: 8.5 L
🔹 Suction Valve: 80 mm
🔹 Discharge Valve: 42 mm
🔹 Net Weight: 355 kg
🔹 Maximum Absorbed Power @ 50 Hz: 60.2 kW
🔹 Maximum Absorbed Power @ 60 Hz: 72.2 kW Dorin
🏭 Typical Applications
The HEX6000CS is suitable for a wide range of commercial and industrial refrigeration applications, including:
❄️ Large cold storage facilities
❄️ Industrial refrigeration systems
❄️ Large walk-in chillers and freezers
❄️ Food processing plants
❄️ Meat and seafood processing facilities
❄️ Supermarket and hypermarket refrigeration
❄️ Refrigerated warehouses
❄️ Logistics and distribution centres
❄️ Marine refrigeration systems
❄️ Ice cream production and storage
Dorin lists commercial refrigeration, industrial refrigeration, marine applications and logistics centres among the applications for the HEX7 range. Dorin
Correct compressor selection should be based on the required refrigeration capacity, refrigerant, evaporating temperature, condensing temperature and electrical supply.
🚚 Shipping & Availability
✅ Standard 50 Hz configurations available
⚙️ 60 Hz and special-voltage configurations available on request
📦 Export-grade packaging for international shipping
🚢 Sea freight options available
✈️ Air freight options available depending on destination
🌍 Worldwide shipping available
Please note: The listed product price does not include shipping.
Contact us with your destination country, city or nearest port to confirm shipping costs.
📥 Technical Support
Contact us for compressor selection, refrigeration capacity, operating conditions, refrigerant selection, voltage requirements and international shipping.
