⚙️ Main Specifications
🔹 Model: HEX3500CC
🔹 Series: HEX6
🔹 Type: Semi-Hermetic Reciprocating Compressor
🔹 Number of Cylinders: 6
🔹 Displacement @ 50 Hz: Approx. 113.75 m³/h
🔹 Displacement @ 60 Hz: Approx. 136.49 m³/h
🔹 Bore: 68 mm
🔹 Stroke: 60 mm
🔹 Oil Charge: 3.5 L
🔹 Suction Valve: 54 mm
🔹 Discharge Valve: 35 mm
🔹 Net Weight: Approx. 246 kg
🔹 Maximum Absorbed Power @ 50 Hz: 39.3 kW
🔹 Maximum Absorbed Power @ 60 Hz: 47.1 kW
These specifications are based on Dorin's current technical information for the HEX3500CC. Dorin
🏭 Typical Applications
The HEX3500CC is suitable for a wide range of commercial and industrial refrigeration applications, including:
❄️ Cold storage facilities
❄️ Industrial refrigeration systems
❄️ Walk-in chillers and freezers
❄️ Food processing plants
❄️ Meat processing facilities
❄️ Seafood processing facilities
❄️ Supermarkets and hypermarkets
❄️ Refrigerated warehouses
❄️ Logistics and distribution centres
❄️ Marine refrigeration systems
Dorin identifies the HEX range for applications including commercial refrigeration, industrial refrigeration and marine systems.
The correct compressor selection depends on the required refrigeration capacity, refrigerant, evaporating temperature, condensing temperature and electrical supply.
💰 Price
Price: USD $7,781.22
Shipping is not included. Please contact us to confirm current availability and freight costs.
🚚 Shipping & Availability
✅ Standard 50 Hz configurations available
⚙️ 60 Hz and special-voltage configurations available on request
📦 Export-grade packaging for international shipping
🌍 Worldwide air and sea freight options available
📥 Technical Support
Contact us for compressor selection, refrigeration capacity, operating conditions, refrigerant selection, voltage requirements and international shipping.
