⚙️ Main Specifications
- 🔹 Model: 2S-H5500L
- 🔹 Series: 2S-H7
- 🔹 Type: Two-Stage Semi-Hermetic Reciprocating Compressor
- 🔹 LP Displacement @ 50 Hz: 183.58 m³/h
- 🔹 HP Displacement @ 50 Hz: 61.19 m³/h
- 🔹 LP Displacement @ 60 Hz: 220.30 m³/h
- 🔹 HP Displacement @ 60 Hz: 73.43 m³/h
- 🔹 LP Cylinders: 6
- 🔹 HP Cylinders: 2
- 🔹 LP / HP Volume Ratio: 3.00
- 🔹 Oil Charge: 8.5 L
- 🔹 Net Weight: 362 kg
- 🔹 Maximum Absorbed Power @ 50 Hz: 52.9 kW
- 🔹 Maximum Absorbed Power @ 60 Hz: 63.4 kW
These figures are from Dorin's official technical data for the 2S-H5500L.
❄️ Typical Applications
Suitable for demanding refrigeration systems such as blast freezers, industrial freezer rooms, frozen-food storage, seafood and meat processing, food production facilities, logistics cold stores and other industrial low-temperature refrigeration systems. Dorin lists industrial refrigeration, commercial refrigeration and marine refrigeration among applications for its compressor range. Dorin
🚚 Shipping & Availability
✅ Standard 380–420V / 50Hz configurations
⚙️ 60Hz and special-voltage options available on request
📦 Export-grade packaging for international shipping
🌍 Air and sea freight options available worldwide
📥 Technical Support
Contact us for compressor selection, refrigeration capacity, operating conditions, voltage requirements and international shipping.
