⚙️ Main Specifications
- 🔹 Model: 2S-H5000L
- 🔹 Series: 2S-H7
- 🔹 Type: Two-Stage Semi-Hermetic Reciprocating Compressor
- 🔹 LP Displacement @ 50 Hz: 166.31 m³/h
- 🔹 HP Displacement @ 50 Hz: 61.19 m³/h
- 🔹 LP Displacement @ 60 Hz: 199.58 m³/h
- 🔹 HP Displacement @ 60 Hz: 73.43 m³/h
- 🔹 LP Cylinders: 6
- 🔹 HP Cylinders: 2
- 🔹 Oil Charge: 8.5 L
- 🔹 Net Weight: 362 kg
- 🔹 LP/HP Volume Ratio: 2.72
These specifications are confirmed by Dorin's official product data.
❄️ Typical Applications
Ideal for demanding low and extra-low-temperature refrigeration systems, including:
- Blast freezers
- Industrial freezer rooms
- Frozen-food cold storage
- Seafood and meat processing facilities
- Food freezing plants
- Industrial refrigeration systems
- Logistics and cold-storage facilities
Dorin lists industrial refrigeration, logistics centers, marine applications and retail among the applications for the 2S-H series.
🚚 Shipping & Availability
✅ Standard 380–420V / 50Hz configurations
⚙️ 60Hz and special-voltage options available on request
📦 Export-grade packaging for international shipping
🌍 Air and sea freight options available worldwide
📥 Technical Support
Contact us for compressor selection, refrigeration capacity, operating conditions, voltage options and international shipping.
