Main Specifications
Brand: Copeland
Model: ZFI09KNE
Compressor Type: Hermetic Scroll Compressor
Application: Low Temperature Refrigeration
Nominal Horsepower: 2 HP
Displacement: 34.5 cc/rev
Technology: Injection Scroll Technology
Frequency: 50 Hz / 60 Hz depending on motor version
Application Type: LBP / Low Temperature
Available Electrical Versions
ZFI09KNE-PFZ-558
-
220–240 V
-
Single Phase
-
50 Hz
-
Stub tube connection
ZFI09KNE-TFD-558
-
380–420 V
-
Three Phase
-
50 Hz
-
460 V
-
Three Phase
-
60 Hz
-
Stub tube connection
This makes the ZFI09KNE-PFZ-558 particularly suitable for refrigeration installations requiring a 2 HP single-phase low-temperature compressor.
Low Temperature Performance
With R404A at 50 Hz and 45°C condensing temperature, Copeland lists approximately:
-
-40°C evaporating: 0.89 kW cooling capacity
-
-35°C evaporating: 1.19 kW
-
-30°C evaporating: 1.53 kW
-
-25°C evaporating: 1.93 kW
-
-20°C evaporating: 2.39 kW
-
-15°C evaporating: 2.93 kW
-
-10°C evaporating: 3.55 kW
Actual refrigeration capacity depends on refrigerant, condensing temperature, evaporating temperature and system design.
Typical Applications
The Copeland ZFI09KNE is suitable for:
-
Walk-in freezers
-
Commercial freezer rooms
-
Low-temperature cold rooms
-
Frozen food storage
-
Meat freezers
-
Seafood and fish storage
-
Supermarket refrigeration
-
Restaurant refrigeration
-
Food processing refrigeration systems
-
Small industrial refrigeration systems
Key Features
-
Designed for low-temperature refrigeration
-
2 HP nominal compressor
-
Scroll compressor technology
-
Compact hermetic design
-
High reliability
-
Efficient low-temperature operation
-
Single-phase option available
-
Three-phase option available
-
Suitable for commercial cold rooms and freezers
-
Available in 50 Hz and 60 Hz configurations depending on model
Why Choose the Copeland ZFI09KNE?
The Copeland ZFI09KNE refrigeration compressor provides a practical solution for low-temperature applications that require dependable cooling performance from a compact scroll compressor.
The availability of the ZFI09KNE-PFZ-558 single-phase 220–240 V version also makes it particularly useful for walk-in freezer projects where three-phase electrical supply is not available.
For correct compressor selection, refrigeration capacity should always be checked according to the required evaporating temperature, condensing temperature, refrigerant and refrigeration load.
