⚙️ Main Specifications
Model: THSD456KS
Brand: BOYARD
Compressor Type: Hermetic Rotary Refrigeration Compressor
Application: MBP / LBP Commercial Refrigeration
Power Supply: 1 Phase, 220–240V
Frequency: 50Hz standard / 60Hz options available
Displacement: 45.6 cc/rev
Rated Speed @ 50Hz: 2850 rpm
Configuration: Horizontal
Number of Cylinders: 2
Height: 200 mm
Refrigerants: R404A / R448A / R449A / R455A / R454C / R452A
❄️ Medium Temperature – MBP
Cooling Capacity: 4,710 W / 16,071 Btu/h
Input Power: 2,771 W
Current: 12.9 A
COP: 1.70 W/W
These performance figures are based on the specified 50Hz test conditions.
🧊 Low Temperature – LBP
Cooling Capacity: 2,530 W / 8,632 Btu/h
Input Power: 2,400 W
Current: 11.4 A
COP: 1.05 W/W
The THSD456KS combines relatively high refrigeration capacity with a compact horizontal configuration, making it particularly suitable for applications where installation height is limited.
🔧 Key Features
- 45.6 cc/rev displacement
- 2-cylinder rotary compressor design
- Compact horizontal configuration
- Only 200 mm in height
- Suitable for MBP and LBP refrigeration
- Single-phase power supply
- 50Hz and 60Hz options available
- Compatible with multiple refrigerants
- High refrigeration capacity in a compact design
- Suitable for commercial refrigeration and condensing units
🏪 Applications
The BOYARD THSD456KS is suitable for:
- Walk-in freezers
- Walk-in chillers
- Cold-room refrigeration systems
- Commercial freezer systems
- Refrigerated display equipment
- Commercial condensing units
- Supermarket refrigeration
- Food and beverage refrigeration
- Medium- and low-temperature commercial refrigeration
