⚙️ Main Specifications
Model: THSD329KS
Brand: BOYARD
Compressor Type: Hermetic Rotary Refrigeration Compressor
Application: MBP / LBP Commercial Refrigeration
Power Supply: 1 Phase, 220–240V
Frequency: 50Hz standard / 60Hz options available
Displacement: 32.9 cc/rev
Rated Speed @ 50Hz: 2850 rpm
Configuration: Horizontal
Number of Cylinders: 2
Height: 200 mm
Refrigerants: R404A / R448A / R449A / R455A / R454C / R452A
❄️ Medium Temperature – MBP
Cooling Capacity: 3,400 W / 11,601 Btu/h
Input Power: 2,000 W
Current: 9.3 A
COP: 1.70 W/W
These performance figures are based on the specified 50Hz test conditions.
🧊 Low Temperature – LBP
Cooling Capacity: 1,850 W / 6,312 Btu/h
Input Power: 1,762 W
Current: 8.0 A
COP: 1.05 W/W
The THSD329KS is designed for both medium- and low-temperature refrigeration systems where a compact horizontal compressor with higher cooling capacity is required.
🔧 Key Features
- 32.9 cc/rev displacement
- 2-cylinder rotary compressor design
- Compact horizontal configuration
- Only 200 mm in height
- Suitable for MBP and LBP refrigeration
- Single-phase operation
- 50Hz and 60Hz options available
- Compatible with multiple refrigerants
- Suitable for commercial refrigeration systems
- Space-saving design for compact condensing units
🏪 Applications
The BOYARD THSD329KS is suitable for:
- Walk-in freezers
- Walk-in chillers
- Cold-room refrigeration systems
- Commercial freezer cabinets
- Refrigerated display equipment
- Commercial condensing units
- Supermarket refrigeration
- Food and beverage refrigeration
- Medium- and low-temperature refrigeration systems
