⚙️ Main Specifications
Model: QHD-30K
Brand: BOYARD
Compressor Type: Hermetic Rotary Refrigeration Compressor
Application: MBP / LBP Commercial Refrigeration
Power Supply: 1 Phase, 220–240V
Frequency: 50Hz standard / 60Hz options available
Displacement: 30.7 cc/rev
Rated Speed @ 50Hz: 2850 rpm
Configuration: Horizontal
Number of Cylinders: 1
Height: 195 mm
Refrigerants: R404A / R448A / R449A / R455A / R454C / R452A
❄️ Medium Temperature – MBP
Cooling Capacity: 3,200 W / 10,918 Btu/h
Input Power: 1,883 W
Current: 8.7 A
COP: 1.70 W/W
These performance figures are based on the specified 50Hz test conditions.
🧊 Low Temperature – LBP
Cooling Capacity: 1,800 W / 6,142 Btu/h
Input Power: 1,714 W
Current: 8.0 A
COP: 1.05 W/W
The QHD-30K provides reliable performance for both medium- and low-temperature refrigeration applications, particularly where installation height is limited.
🔧 Key Features
- 30.7 cc/rev displacement
- Compact horizontal rotary design
- Only 195 mm in height
- Suitable for MBP and LBP refrigeration
- Single-phase operation
- 50Hz and 60Hz options available
- Compatible with multiple refrigerants
- Space-saving installation
- Suitable for commercial refrigeration equipment
- Suitable for cold-room and freezer condensing units
🏪 Applications
The BOYARD QHD-30K is suitable for:
- Walk-in freezers
- Walk-in chillers
- Cold-room refrigeration systems
- Commercial freezer cabinets
- Refrigerated display equipment
- Commercial condensing units
- Supermarket refrigeration
- Food and beverage refrigeration
- Compact refrigeration systems
- Medium- and low-temperature refrigeration equipment
