⚙️ Main Specifications
Model: QHD-16K
Brand: BOYARD
Compressor Type: Hermetic Rotary Refrigeration Compressor
Application: MBP / LBP Commercial Refrigeration
Power Supply: 1 Phase, 220–240V
Frequency: 50Hz standard / 60Hz options available
Displacement: 16.4 cc/rev
Rated Speed @ 50Hz: 2850 rpm
Configuration: Horizontal
Number of Cylinders: 1
Height: 185 mm
Refrigerants: R404A / R448A / R449A / R455A / R454C / R452A
❄️ Medium Temperature – MBP
Cooling Capacity: 2,070 W / 7,063 Btu/h
Input Power: 1,035 W
Current: 4.9 A
COP: 2.00 W/W
These performance figures are based on the specified 50Hz test conditions.
🧊 Low Temperature – LBP
Cooling Capacity: 1,000 W / 3,412 Btu/h
Input Power: 950 W
Current: 4.5 A
COP: 1.05 W/W
The QHD-16K is suitable for both medium- and low-temperature refrigeration systems, providing flexibility across a variety of commercial refrigeration applications.
🔧 Key Features
- Horizontal compact design with only 185 mm height
- 16.4 cc/rev displacement
- Suitable for MBP and LBP refrigeration
- Single-phase operation
- 50Hz and 60Hz options available
- Multiple refrigerant compatibility
- Compact installation footprint
- Suitable for commercial refrigeration and condensing units
- Designed for applications where installation height is limited
🏪 Applications
The BOYARD QHD-16K can be used for:
- Commercial refrigeration cabinets
- Display chillers and freezers
- Commercial freezers
- Cold-room refrigeration systems
- Condensing units
- Food and beverage refrigeration
- Compact refrigeration equipment
- Transport and mobile refrigeration applications
