⚙️ Main Specifications
Model: QHD-13K
Brand: BOYARD
Compressor Type: Rotary Refrigeration Compressor
Application: MBP / LBP Commercial Refrigeration
Power Supply: 1 Phase, 220–240V, 50Hz
Displacement: 13.5 cc/rev
Rated Speed: 2850 rpm
Configuration: Horizontal
Number of Cylinders: 1
Height: 185 mm
Refrigerants: R404A / R448A / R449A / compatible A2L refrigerants Boyard Compressors
❄️ Medium Temperature – MBP
Cooling Capacity: 1,700 W / 5,800 Btu/h
Input Power: 850 W
Current: 3.9 A
COP: 2.00 W/W
The MBP rating is based on an evaporating temperature of -6.7°C, condensing temperature of 54.5°C, suction temperature of 18.3°C and liquid temperature of 32.2°C. Boyard Compressors
🧊 Low Temperature – LBP
Cooling Capacity: 820 W / 2,798 Btu/h
Input Power: 780 W
Current: 3.6 A
COP: 1.05 W/W
The LBP rating is based on an evaporating temperature of -23.3°C and condensing temperature of 54.5°C. Boyard Compressors
🔧 Key Features
The QHD-13K offers a wide evaporating-temperature range from approximately -5°C to -40°C and uses liquid-injection cooling technology to support stable compressor operation under demanding conditions. Its horizontal design makes it particularly useful for compact refrigeration systems where vertical installation space is restricted. Boyard Compressors
It is suitable for applications such as:
- Commercial refrigeration cabinets
- Refrigerated display cases
- Freezers and chillers
- Commercial condensing units
- Food and beverage refrigeration
- Transport refrigeration
- Compact refrigeration systems
QHD-13K vs QXD-13K
The QHD-13K and QXD-13K have essentially the same 13.5 cc/rev displacement and rated MBP/LBP capacities, but the main difference is their physical configuration:
QHD-13K = Horizontal, 185 mm high
QXD-13K = Vertical, 310 mm high Boyard Compressors
